Pilz PNOZ mo4p User Manual

Commissioning
Operating Manual PNOZ mo4p
20942-EN-08
| 17
6 Commissioning
6.1 General wiring guidelines
The wiring is defined in the circuit diagram of the PNOZmulti Configurator.
Please note:
} Information given in the Technical details [ 20] must be followed.
} The position of the expansion module is specified in the Hardware configuration of the
PNOZmulti Configurator.
} Use copper wiring with a temperature stability of 75 °C.
6.2 Connection
Redundant
O1 (3)
K1
L1
N
K2
14 (34)
13 (33)
23 (43)
24 (44)
O0 (2)
single
O1 (3)
K1
L1
N
K2
14 (34)
13 (33)
23 (43)
24 (44)
O0 (2)
Feedback loop Redundant output
Contacts from external contactors
O1 (3)
K1
L1
N
K2
14 (34)
13 (33)
23 (43)
24 (44)
O0 (2)
L+
I0
