Technical details
Operating Manual PNOZ mo4p
20942-EN-08
| 23
Mechanical data 773536 773537
Conductor cross section with screw
terminals (relay outputs)
1 core flexible 0,25 - 2,50 mm², 24 - 12 AWG 0,25 - 2,50 mm², 24 - 12 AWG
2 core with the same cross sec-
tion, flexible without crimp con-
nectors or with TWIN crimp con-
nectors 0,25 - 1,50 mm², 24 - 16 AWG 0,25 - 1,50 mm², 24 - 16 AWG
Torque setting with screw terminals
(relay outputs)
0,50 Nm 0,50 Nm
Stripping length with screw termin-
als (relay outputs)
8 mm 8 mm
Conductor cross section with
spring-loaded terminals (relay out-
puts)
1 core flexible without crimp
connector 0,25 - 2,50 mm², 24 - 12 AWG 0,25 - 2,50 mm², 24 - 12 AWG
1 core flexible with crimp con-
nector 0,25 - 1,50 mm², 24 - 16 AWG 0,25 - 1,50 mm², 24 - 16 AWG
Spring-loaded terminals: Terminal
points per connection
1 1
Stripping length with spring-loaded
terminals (relay outputs)
10 mm 10 mm
Dimensions
Height 94,0 mm 94,0 mm
Width 22,5 mm 22,5 mm
Depth 121,0 mm 121,0 mm
Weight 204 g 204 g
Where standards are undated, the 2009-01 latest editions shall apply.
8.1 Safety characteristic data
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN62061
SIL CL
EN62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
1-channel PL c Cat. 1 - 2,90E-08 - 2,60E-03 20
2-channel PL e Cat. 4 SIL CL 3 3,00E-10 SIL 3 5,20E-07 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
