Technical details
Operating Manual PNOZ mo4p
20942-EN-08
| 22
Environmental data 773536 773537
Condensation during operation
Not permitted
Short-term (only with separated
extra low voltage)
EMC EN 61131-2 EN 61131-2
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10,0 - 150,0 Hz 5,0 - 500,0 Hz
Acceleration 1g 1g
Broadband noise
In accordance with the standard – EN 60068-2-64
Frequency – 5 - 500 Hz
Acceleration – 1,9grms
Corrosive gas check
SO2: Concentration 10ppm,
duration 10days, passive – DIN V 40046-36
H2S: Concentration 1ppm, dur-
ation 10days, passive – DIN V 40046-37
Shock stress
In accordance with the standard EN 60068-2-27 EN 60068-2-27
Acceleration 15g 15g
Duration 11 ms 11 ms
Max. operating height above sea
level
2000 m 2000 m
Airgap creepage
In accordance with the standard EN 61131-2 EN 61131-2
Overvoltage category III III
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 6,00 kV 6,00 kV
Protection type
In accordance with the standard EN 60529 EN 60529
Mounting area (e.g. control cab-
inet) IP54 IP54
Housing IP20 IP20
Terminals IP20 IP20
Mechanical data 773536 773537
Mounting position horizontally on mounting rail horizontally on mounting rail
DIN rail
Top hat rail 35 x 7,5 EN 50022 35 x 7,5 EN 50022
Recess width 27 mm 27 mm
Material
Bottom PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0
Connection type Spring-loaded terminal, screw
terminal
Spring-loaded terminal, screw
terminal
