Technical details
Operating Manual PNOZ mo4p
20942-EN-08
| 21
Relay outputs 773536 773537
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 3,0 A 3,0 A
Max. power 690 W 690 W
DC13 (6 cycles/min) at 24 V 24 V
Max. current 3,0 A 3,0 A
Max. power 72 W 72 W
AC15 at – 230 V
Max. current – 2 A
Max. power – 460 W
DC13 (6 cycles/min) at – 24 V
Max. current – 2 A
Max. power – 48 W
Max. permitted total current of relay
outputs at an ambient temperature
of > 50°C
12 A –
Airgap creepage between
Relay contacts 3 mm 3 mm
Relay contacts and other circuits 5,5 mm 5,5 mm
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 6,00 A 6,00 A
Circuit breaker 24V AC/DC,
characteristic B/C 6 A 6 A
Switch-off delay 50 ms 50 ms
Conventional thermal current 12,0 A 12,0 A
Times 773536 773537
Switch-on delay 5,00 s 5,00 s
Supply interruption before de-ener-
gisation
20 ms 20 ms
Environmental data 773536 773537
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range 0 - 60 °C -25 - 60 °C
Forced convection in control
cabinet off 55 °C –
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -25 - 70 °C -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78 EN 60068-2-30, EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
