PNOZ s2
Operating Manual PNOZ s2
21394-EN-11
| 19
Relay outputs 750102 751102
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 W 0,04 W
Max. power 150 W 150 W
Utilisation category of auxiliary con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 W 0,04 W
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 5 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 5 A 5 A
Utilisation category of auxiliary con-
tacts
AC15 at 230 V 230 V
Max. current 5 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 5 A 5 A
