PNOZ s2
Operating Manual PNOZ s2
21394-EN-11
| 18
Technical Details
General 750102 751102
Certifications
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
Electrical data 750102 751102
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 2 W 2 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Inputs 750102 751102
Number 1 1
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 75 mA 75 mA
Start circuit DC 7 mA 7 mA
Feedback loop DC 7 mA 7 mA
Max. inrush current impulse
Current pulse, input circuit 0,5 A 0,5 A
Pulse duration, input circuit 7 ms 7 ms
Current pulse, feedback loop 0,5 A 0,5 A
Pulse duration, feedback loop 30 ms 30 ms
Current pulse, start circuit 0,5 A 0,5 A
Pulse duration, start circuit 30 ms 30 ms
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Semiconductor outputs 750102 751102
Number 1 1
Voltage 24 V 24 V
Current 20 mA 20 mA
Residual current at "0" signal 0,1 mA 0,1 mA
Max. internal voltage drop 5 V 5 V
Conditional rated short circuit cur-
rent 100 A 100 A
Lowest operating current 0 mA 0 mA
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
