Operating Manual PNOZ s2
21394-EN-11
| 21
Times 750102 751102
Switch-on delay
With automatic start typ. 75 ms 75 ms
With automatic start max. 250 ms 250 ms
With automatic start after power
on typ. 75 ms 75 ms
With automatic start after power
on max. 250 ms 250 ms
With manual start typ. 75 ms 75 ms
With manual start max. 250 ms 250 ms
With monitored start with rising
edge typ. 75 ms 75 ms
With monitored start with rising
edge max. 250 ms 250 ms
With monitored start with falling
edge typ. 55 ms 55 ms
With monitored start with falling
edge max. 70 ms 70 ms
Delay-on de-energisation
With E-STOP typ. 50 ms 50 ms
With E-STOP max. 70 ms 70 ms
With power failure typ. 50 ms 50 ms
With power failure max. 70 ms 70 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 100 ms 100 ms
After power failure 100 ms 100 ms
Waiting period with a monitored
start
With rising edge 100 ms 100 ms
With falling edge 110 ms 110 ms
Min. start pulse duration with a
monitored start
With rising edge 100 ms 100 ms
With falling edge 100 ms 100 ms
Supply interruption before de-ener-
gisation 10 ms 10 ms
Environmental data 750102 751102
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
