Pilz PNOZ s2 User Manual

PNOZ s2
Operating Manual PNOZ s2
21394-EN-11
| 28
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product type Features Connection type Order no.
PNOZ s2 24 V DC Screw terminals 750102
PNOZ s2 C 24 V DC Spring-loaded terminals 751102
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/downloads.
Authorised representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2,
73760 Ostfildern, Germany

Pilz PNOZ s2 Specifications

General

Brand	Pilz
Model	PNOZ s2
Category	Relays
Language	English
