Pilz PNOZ s7 User Manual

PNOZ s7
Operating Manual PNOZ s7
21399-EN-10
15
Relay outputs 750107 751107 751187
Utilisation category in ac-
cordance with UL
Voltage
240 V AC G.U. (same po-
larity)
240 V AC G.U. (same po-
larity)
240 V AC G.U. (same po-
larity)
With current 6 A 6 A 6 A
Voltage 24 V DC G. U. 24 V DC G. U. 24 V DC G. U.
With current 6 A 6 A 6 A
External contact fuse pro-
tection, safety contacts
In accordance with the
standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Max. melting integral 260 A²s 260 A²s 260 A²s
Blow-out fuse, quick 10 A 10 A 10 A
Blow-out fuse, slow 6 A 6 A 6 A
Blow-out fuse, gG 10 A 10 A 10 A
Circuit breaker 24V
AC/DC, characteristic
B/C
6 A 6 A 6 A
External contact fuse pro-
tection, auxiliary contacts
Max. melting integral 160 A²s 160 A²s 160 A²s
Blow-out fuse, quick 4 A 4 A 4 A
Blow-out fuse, slow 2 A 2 A 2 A
Blow-out fuse, gG 4 A 4 A 4 A
Circuit breaker 24 V
AC/DC, characteristic
B/C
2 A 2 A 2 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
Conventional thermal
current while loading
several contacts
750107 751107 751187
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 6 A 6 A 6 A
Conv. therm. current
with 2 contacts 5,5 A 5,5 A 5,5 A
Conv. therm. current
with 3 contacts 4,5 A 4,5 A 4,5 A
Conv. therm. current
with 4 contacts
4 A 4 A 4 A
Times 750107 751107 751187
Switch-on delay
With automatic start
after power on typ. 30 ms 30 ms 30 ms
With automatic start
after power on max.
50 ms 50 ms 50 ms
