Pilz PNOZ s7 User Manual

PNOZ s7
Operating Manual PNOZ s7
21399-EN-10
17
Mechanical data 750107 751107 751187
Conductor cross section
with screw terminals
1 core flexible
0,25 - 2,5 mm², 24 - 12
AWG – –
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1 mm², 24 - 16
AWG – –
2 core with the same
cross section, flexible
without crimp connect-
ors or with TWIN crimp
connectors
0,2 - 1,5 mm², 24 - 16
AWG
– –
Torque setting with screw
terminals
0,5 Nm – –
Conductor cross section
with spring-loaded termin-
als: Flexible with/without
crimp connector
–
0,2 - 2,5 mm², 24 - 12
AWG
0,2 - 2,5 mm², 24 - 12
AWG
Spring-loaded terminals:
Terminal points per con-
nection
– 2 2
Stripping length with
spring-loaded terminals
– 9 mm 9 mm
Dimensions
Height 98 mm 100 mm 100 mm
Width 17,5 mm 17,5 mm 17,5 mm
Depth 120 mm 120 mm 120 mm
Weight 170 g 170 g 170 g
Where standards are undated, the 2014-07 latest editions shall apply.
