Pilz PNOZ X2.8P User Manual

PNOZ X2.8P
Operating Manual PNOZ X2.8P
1004082-EN-20
| 20
Conventional thermal current
while loading several contacts
777301 777302
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 6 A 6 A
Conv. therm. current with 2 con-
tacts 6 A 6 A
Conv. therm. current with 3 con-
tacts 5 A 4,5 A
Times 777301 777302
Switch-on delay
With automatic start typ. 250 ms 340 ms
With automatic start max. 450 ms 400 ms
With automatic start after power
on typ. 250 ms 600 ms
With automatic start after power
on max. 450 ms 800 ms
With manual start typ. 125 ms 180 ms
With manual start max. 450 ms 400 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 10 ms
With E-STOP max. 30 ms 20 ms
With power failure typ. 60 ms –
With power failure max. 100 ms –
With power failure typ. UB 240 V – 1100 ms
With power failure max. UB 240
V – 1500 ms
With power failure typ. UB 24 V – 180 ms
With power failure max. UB 24 V – 230 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 200 ms 1500 ms
Supply interruption before de-ener-
gisation 20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 777301 777302
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -35 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
