PNOZ X2.8P
Operating Manual PNOZ X2.8P
1004082-EN-20
| 13
Preparing for operation
Supply voltage AC DC
U
B
= 24 VAC/DC;
Order no. 777301, 787301
A1
A2
L1
N
A1
A2
L+
L-
U
B
= 24 - 240 VAC/DC;
Order no. 777302, 787302
A1
A2
L1
N
S21
A1
A2
L+
L-
S21
Input circuit Single-channel Dual-channel
E-STOP
without detection of shorts
across contacts
S1
S22
S21
S11
S52
S12
S1
S11
S12
S52
S22
S21
E-STOP
with detection of shorts across
contacts
S1
S22
S21
S12
S11
S52
S11
Safety gate
without detection of shorts
across contacts
S1
S22
S21
S11
S52
S12
S1
S2
S22
S21
S11
S12
S52
Safety gate
with detection of shorts across
contacts
Light guards or safety switch, de-
tection of shorts across contacts
via ESPE
(only when U
B
= 24 VDC);
Order no. 777301, 787301)
