PNOZ X2.8P
Operating Manual PNOZ X2.8P
1004082-EN-20
| 31
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product type Features Connection type Order no.
PNOZ X2.8P 24 VAC/DC Screw terminals 777301
PNOZ X2.8P C 24 VAC/DC Spring-loaded terminals 787301
PNOZ X2.8P 24 - 240 VAC/DC Screw terminals 777302
PNOZ X2.8P C 24 - 240 VAC/DC Spring-loaded terminals 787302
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/support/downloads.
Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost-
fildern, Germany

Pilz PNOZ X2.8P Specifications

General

Brand	Pilz
Model	PNOZ X2.8P
Category	Relays
Language	English
