Pioneer DJM-600 Service Manual

DJM-600
18
A
B
C
D
1
23
4
1234
3.6 VR (2/6), FADER VR (MAIN) and HP JACK ASSYS
D 2/6
FADER VR (MAIN)
ASSY (DWG1520)
E
FADER START SW (CH2)
MONITER BALANCE
MONO SW
FADER VR (MAIN)
VR ASSY (2/6)
(DWG1517)
MONO
STEREO
D
1/6
D
1/6
D
3/6
D
3/6
& IC202 - pin1
V: 0.2V/div
H: 0.2msec/div
&
(
*
GND
* TP- MTLI
V: 0.2V/div
H: 0.2msec/div
GND
( IC203 - pin1
V: 0.2V/div
H: 0.2msec/div
GND
_ TP- MPML
V: 0.5V/div
H: 0.2msec/div
GND
+ TP- HPLI
V: 0.2V/div
H: 0.2msec/div
GND
+
_
2/6
D
E

Pioneer DJM-600 Specifications

General

Channels	4
Frequency Range	20 Hz - 20 kHz
Weight	6.6 kg
Fader Start	Yes
Output Terminals	RCA, XLR
Outputs	MASTER OUT, BOOTH OUT, REC OUT
Dimensions	320 mm (W) x 107.5 mm (H) x 372 mm (D)
EQ	3-band per channel
Effects	Delay, Echo, Auto Pan, Flanger, Reverb, Pitch Shifter
Power Supply	AC 220 - 240 V, 50/60 Hz
Inputs	3 PHONO, 4 LINE, 2 MIC
