14
PANEL FACILITIES
5-1
1 Power ( )
Turns the monitor’s power on and off.
2 Remote sensor window
Receives the signals from the remote control.
3 STANDBY/ON indicator
When the power is on ............................. Lights green.
When the power is in the standby mode ... Lights red.
4 INPUT/EXIT
Switches the input.
The available inputs depend on the setting of “BNC
INPUT”, “RGB SELECT” and “DVI SET-UP”.
Functions as the EXIT buttons in the On-Screen
Display (OSD) mode.
Front View
456
7
1 3 2
5 LEFT/– and RIGHT/+
Functions as the CURSOR (
/ ) buttons in the On-
Screen Display (OSD) mode.
6 VOLUME
and
Adjusts the volume. Functions as the CURSOR (▲/
▼) buttons in the On-Screen Display (OSD) mode.
7 MENU/SET
Sets the On-Screen Display (OSD) mode and displays
the main menu.
WARNING
The Power on/off switch does not disconnect the plasma
display completely from the supply mains.
PDP-424MV
