68
3 Repeat the procedures of 1 and 2 above, and enter all inputs of [DISS00001XX] from the left side.
(7) Following the above, setting must be carried out without fail according to "3-2. Factory shipment
setting (Initial setting)"
3-2.Factory shipment setting (Initial setting)
(1) Press the [MENU/ENTER] ke to select the [FUNCTION] menu.
(2) Move the POSITION/CONTROL keys of [ ] and [ ] to the item of [SHIP]. Then, move the
POSITION/CONTROL keysof [ ] and [ ] to select [DESTINATION ALPHABETS] shown below.
(The asterisks * shown below denote the numerals or the characters.)
J : PDP-424MV-FI JW : For use in Japan
A : PDP-424MV AW :
For use in Japan and North America
G : PDP-42MVE1
Nothing
GW : For European countries
W : WW :
Specifications for zones other than the above
(3) Press the keys in the order of [MUTE]→POSITION/CONTROL [ ] → POSITION/CONTROL
[ ] →[OFF TIMER] to make "Factory shipment setting". When "Factory shipment setting" is
executed, the red characters of [SET] is shown for about 5 seconds on the right side of the
[DESTINATION ALPHABETS]. The setting is finished when these red characters of [SET] go out. In
regard to the factory shipment setting values, refer to the descriptions given below.
FUNCTION
SCART OFF SAFEL MODE ---
SHIP A PLE TEST OFF --
LIMIT-VD OFF VD2VLIM 5HZ
LIMIT-PC ON VD2 YCORB --
GAMMA MD 12 VD2 YCOREN ON
VOL OFFSET 2 VD2 CORB --
FHCRT COMP 3 VD2 COREN ON
ACTVH TIME 2 VD OUT 10
PSC-T OFF ROTATEPTN 1
EXT-PC OFF BLUEGAIN OFF
[MENU/ENTER] NEXT [EXIT] PREV
MONITOR INFORMATION
MODEL NAME
: PDP-424MV
SERIAL/NUMBER
: DISS00001XX
SOFT WARE VERSION
: F123
T1 025 T2 025
T3 025 T4 - -
[MENU/ENTER] NEXT [EXIT] PREV
USAGE TIME
: 0000 0H
9-4
To Next Page
