Part Names
04
Part Names
Plasma Display
1POWER
button
2
STANDBY indicator
3
POWER ON indicator
4
Remote control sensor
5
SPEAKER (right/left) terminals
6
SYSTEM CABLE terminal (BLACK)
7
SYSTEM CABLE terminal (WHITE)
8
AC IN terminal
4
2
3
1
Front view
SYSTEM
CABLE
WHITE
BLACK
SYSTEM
CABLE
WHITE
BLACK
5
6
7
8
Rear view
