Page #17 background imageLoading...
Page #17 background image
17
En
02
About Control Function
with HDMI
The functions work when a control function with
HDMI-compatible Pioneer TV or AV system (AV
receiver or amplifier, etc.) is connected to the
player using an HDMI cable.
Also refer to the operating instructions for the TV
and AV system (AV receiver or amplifier, etc.).
To use the control function with
HDMI
The control function with HDMI operates when
control function with HDMI is set to On for all
devices connected with HDMI cables.
Once the connections and the settings of all
the devices are finished, be sure to check that
the player’s picture is output to the TV. (Also
check after changing the connected devices
and reconnecting HDMI cables.) The control
function with HDMI may not operate properly if
the player’s picture is not properly output to
the TV.
For some models, the control function with
HDMI may be referred to as “KURO LINK” or
“HDMI Control”.
The control function with HDMI does not work
with devices of other brands, even if this player
is connected with an HDMI cable.
What the control function with
HDMI can do
Operating the player with the TV’s remote
control.
Such player operations as starting and
stopping playback and displaying the menus
can be performed from the TV.
The player’s playback picture is displayed on the
TV’s screen. (Auto-select function)
The input switches automatically on the TV and
AV system (AV receiver or amplifier, etc.) when
playback is started on the player or the HOME
MENU is displayed. When the input is switched,
the playback picture, the HOME MENU appears
on the TV.
The power of the TV and the player turns on and
off automatically. (Simultaneous power function)
When playback on the player is started or the
HOME MENU is displayed, if the TV’s power
was off, its power turns on automatically. When
the TV’s power is turned off, the player’s power
automatically turns off.
Setting the HDMI Mode
The UDP-LX500 has two HDMI OUT (MAIN, SUB)
terminals. See page 15 for the details on these
terminals.
To make the setting, press HOME MENU to display
the Home Menu, select Initial Setup HDMI HDMI
Mode.
Pressing the HDMI button on the remote control
will display the current HDMI Mode setting on the
player’s front panel display. To switch the setting,
press HDMI button again.
See the table below and set up the HDMI Mode
according to your connection style.
HDMI
Mode
HDMI OUT MAIN HDMI OUT SUB
Video Audio Control Video Audio Control
Single ✓✓
Separate ✗✗✗
Pure
Audio
✗✗✗
