14
XR-A6800, XR-A4800
Mark No. Description Part No.Mark No. Description Part No.
•
DECK MECHANISM UNIT PARTS LIST
1 Assy’y HD Holder 50-093-4373
2 Assy’y HD Holder 50-093-4104
3 Frame HD 50-219-3024
4 Plate AZ 50-119-4046
5 Spring AZ 50-160-4108
6 Lever HD 50-259-3342
11 Chassis HD 50-112-3045
12 Cap Pinch R 50-219-4033
13 Cap Pinch L 50-219-4034
14 Roller Pinch 50-027-41054
15 Ass’y Plate D 50-219-4311
16 Cap Reel 50-228-4020
17 Gear Reel 50-222-4006
18 Lever ST 50-259-4041
19 Guide C 50-219-4014
20 Lever Brake 50-259-3251
22 Arm SW 50-239-4027
23 Arm CS 50-239-4026
25 Ass’y Cover 50-093-4063
26 Ass’y Flywheel LA 50-093-3366
27 Arm Trigger 50-268-3016
28 Arm Cam 50-139-4292
29 Gear Cam 50-221-3009
30 Coller 03-300-4455
31 Ass’y Flywheel RA 50-093-3360
32 Ass’y Clutch 50-093-4069
33 Arm UD A 50-239-4017
34 Gear UD 50-222-4007
35 Pulley D 50-223-4254
36 Plunger 03-300-4442
37 Ass’y Bobbin 50-093-4125
39 Ass’y Motor 50-093-4316
41 Belt BR 02-084-4205
42 Belt AR 02-084-4203
43 Belt FR 02-083-4188
45 PCB HD 50-070-4057
46 Housing S5BPHKS
47 Housing S3BPHKS
48 Pulley IDL 50-223-4023
50 Ass’y PCB 50-093-4363
51 Ass’y Flywheel L 50-093-3367
52 Ass’y Flywheel RB 50-093-3361
53 Pulley 33-229-4264
60 Spring 01-081-4601
61 Spring 01-082-4652
62 Spring 01-082-4651
63 Spring 01-082-4650
64 Spring 01-080-4649
65 Spring 01-080-4607
66 Spring 01-080-4635
67 Spring 01-082-4654
68 Spring 01-082-4598
69 Spring 01-082-4597
70 Spring 01-081-4657
80 Screw GSE10A2003
81 Screw GSE20A2005
82 Screw GSE10A2004
83 Screw GSD10A2018
84 Screw 03-300-4056
85 Screw GSL10A1704
86 Screw GSP10A2603
87 Screw GSP11A2012
88 Screw GSE20A2004
100 Washer GWN21X040040
101 Washer GWM19X055035S
102 Washer GWM19S035035
103 Washer GWM17S050035S
104 Washer GWM48X075010
105 Washer GWP23X040020
106 Washer GWP21X045020
107 Washer GWP12X030040S
