47
XR-A6800, XR-A4800
Mark No. Description Part No.
Mark No. Description Part No.
DISPLAY ASSY
XWZ3311 and XWZ3298 are constructed the same except for the following :
I
Mark Symbol and Description
Part No.
Remarks
XWZ3311 XWZ3298
Q5656-Q5658
D5561, D5562
D5593
D5601-D5608, D5618, D5622
D5617, D5621
D5652-D5655, D5657, D5658
R3908
R5561, R5562
R5570, R5571
R5601, R5613, R5617
R5618, R5620, R5622
R5619, R5621, R5623
2SC2412K
1SS181
1SS133
SLP3118C51H
SLP6118C51H
1SS355
RS1/16S122J
RS1/16S152J
RS1/16S473J
RD1/4PU151J
RS1/16S222J
RS1/16S330J
Not used
Not used
Not used
Not used
Not used
Not used
RS1/16S681J
Not used
Not used
Not used
Not used
Not used
Mark No. Description Part No.
Mark No. Description Part No.
PCB PARTS LIST FOR XR-A6800/MYXJ UNLESS OTHERWISE NOTED
FM/AM TUNER MODULE
SEMICONDUCTORS
IC6201 LA1832ML
IC6202 LC72131MD
Q6102 2SC2223
Q6203 2SC2705
Q6201,Q6202 2SC2712
Q6103,Q6214,Q6601 2SC2714
Q6104,Q6105 2SK302
Q6101 3SK194
Q6204 DTA124ES
Q6205 DTC124EK
D6202 1SS254
D6101-D6104 1SV228
COILS AND FILTERS
L6106 FM COIL ATC1003
L6105 FM RF COIL ATC1015
L6101 FM ANTENNA COIL ATC1016
L6102 FM ANTENNA COIL ATC1017
L6103 FM RF DRIVE COIL ATC1018
L6104 FM RF TUNIG COIL ATC1019
F6203 FM CERAMIC FILTER ATF-119
F6206 FM CERAMIC DISCLI. ATF7008
F6601 ANTI BIRDY FILTER ATF7009
F6204 FM CERAMIC FILTER ATF7010
F6202 AM CERAMIC FILTER ATF7011
L6107 CHIP COIL ATH1043
L6603 LAU220J
L6206,L6208,L6605 LAU2R2J
TRANSFORMERS
T6201 ATB7008
T6101 ATE7002
CAPACITORS
C6113,C6212,C6274,C6275,C6611 CCSQCH101J50
C6116,C6208,C6221 CCSQCH150J50
C6222 CCSQCH180J50
C6271 CCSQCH200J50
C6117 CCSQCH330J50
C6608 CCSQCH680J50
C6118 CCSQCH8R0D50
C6111,C6122 CCSQCK1R0C50
C6112,C6127 CCSQCK2R0C50
C6105 CCSQSL471J50
C6101 CCSQTH110J50
C6119 CCSQTH150J50
C6109 CCSQTH270J50
C6107,C6110 CCSQTH300J50
C6106 CCSQTH330J50
C6234,C6235 CEAL1R0M50
C6245 CEAL470M16
C6224 CEAS100M50
C6243 CEAS101M16
C6231 CEAS1R0M50
C6227 CEAS220M16
C6236 CEAS2R2M50
C6216 CEAS330M16
C6262 CEAS3R3M50
C6219 CEAS470M10
C6244 CEAS470M16
C6249,C6250,C6265,C6266 CEAS4R7M50
C6258 CEJA470M16
C6215 CFTLA103J50
C6214 CFTLA224J50
A
PRIMARY ASSY
XWZ3312 and XWZ3299 are constructed the same except for the following :
H
Mark Symbol and Description
Part No.
Remarks
XWZ3312 XWZ3299
L1 LINE FILTER ATF1136 XTF3001
