Pitco SEH50 - Pump Box and Drain Manifold

30
L22-238 Rev 0 (08/03)
Table 2
Pump Box and Drain Manifold
Item# Part# Part Description
1..................... 60130301 .............................. 120/24V Transformer
60130302 .............................. 230-240/24VAC Transformer
60130303 .............................. 208VAC Transformer
2..................... 60077901 .............................. 10A Circuit Breaker (120V)
60078502.............................. 5A Circuit Breaker (208V-240V)
3..................... PP11058................................ 24VAC SPST Relay (120V)
60104701.............................. 24VAC DPDT Relay (208-240V)
4..................... 60130701 .............................. Conn, Pwr In & Out IEC320
5..................... 60138701 .............................. Drain Valve, Full/Right Split, W/Non-locking Handle
60138703.............................. Drain Valve, Full/Right Split, W/Locking Handle
6..................... A7021701 ............................. Drain Valve Nipple
7..................... A7022201 ............................. Drain Flange
8..................... A7022101 ............................. Drain Ferrule
9..................... B6665101 ............................. Drain Elbow
10................... 60088002 .............................. Hex Bolt 3/8”x16x1-1/4”
11................... P0082700 .............................. Lock Washer 3/8”
12................... 60127701 .............................. Drain Line Clamp
13................... 60059302 .............................. Drain Line Gasket
14................... B6664701 ............................. Drain Down Spout Full/Full
B6673301 ............................. Drain Down Spout Split
15................... 60138702 .............................. Drain Valve, Left Split, W/Non-locking Handle
60138704.............................. Drain Valve, Left Split, W/Locking Handle
16....................Contact Factory .................... Drain Line Tube
17....................PP10263 ............................... DVI Actuator
18....................B5305001 ............................. DVI Switch Assembly
19....................PP10266 ............................... Screw, 4-40 X .250 RDH ZN
