Pitco SEH50 - Main Entrance Box

32
L22-238 Rev 0 (08/03)
Table 3
Main Entrance Box
Item# Part# Part Description
1 ................. 60132702 ....................... Relay Board Fuse, 1.5A Time Delay
2 ................. 60127301 ....................... Relay Board
................... 60132901 ....................... Relay Board Insulation
3 ................. P5047301 ....................... 3 Post Terminal Block
4 ................. 60139201 ....................... Heat Demand Contactor
5 ................. PP10560......................... Side On Contactor
6 ................. PP10429......................... Transformer 120/208/240VAC
7 ................. 60140701 ....................... Rcpt,10A-250V IE320F Screw In
8 ................. P5045282 ....................... 4 Post Terminal Block
9 ................. B5305001....................... DVI Return Switch
PP10263......................... DVI Return Actuator (not shown)
