pitsco tetrix prime User Manual

Set Screw Applications
Shaft Servo Hub 40230
Wheel with Tire 40222
80-Tooth Plastic Gear 40224
40-Tooth Plastic Gear 40223
D-Shaft Set Collar 40229
Beam Attachment Hub 40228
TIP: Please keep in mind that if your
parts already have socket head cap screws
installed and the directions call for that
operation, you can skip to the next step.
TIP: Directions will show these types of
parts in proper position. After the parts are
in place, don’t forget to tighten the socket
head cap screws before moving on to the
next step.
TIP: Socket head cap screws should be
snug but not overtightened. overtightening
socket head cap screws can damage
components.
56 Building and Coding the PULSE CodeeBot
