EUSING AND LOOKING AFTER THE MANUALS
This manual is common to all MC box models and illustrates the main characteristics of
the various models, providing information on:
• electrical and mechanical installation
• first start up operations
• daily use
This manual DOES NOT cover other aspects such as:
• configuration and operation of the Control system
For these aspects, refer to the specific manuals which accompany each station
model.
For the installer's convenience, all supplied manuals are grouped together in an
envelope. This collection of manuals represents an integral and essential part of the
product and, according to the provisions of directive EEC 89/392, must be given to
operators and maintenance staff in order to comply with the obligations relating to
training/information referred to in directive EEC 89/391.
Carefully read the instructions contained in these manuals, as these are most important
for installation safety, operation and maintenance.
The manufacturer shall not be responsible for damage caused to persons, to property
or to the product that derive from improper use.
Look after this manual carefully in a place protected from damp, heat, dust, oils,
greases, etc., as it will be useful for future reference and consultation. Do not remove,
tear or amend any parts of the manual for any reason. In case of loss or damage, ask
the manufacturer for a copy, quoting the manual code.
This manual must always remain with the machine; in the event of the machine being
sold, it must be given to the new user.
The MC BOX has an identification plate that reads:
• Model
• Serial number / Year of manufacture
• Technical Specifications
• CE mark
8
The company reserves the right to change MC BOX features and specifications
at any time.
WARNING
E.1IDENTIFICATION PLATE
MANUFACTURER
PRODUCT CODE
(see table)
YEAR OF MANUFACTURE
TECHNICAL
SPECIFICATIONS
(see table)
“CE” MARK
SERIAL NUMBER
PRODUCT NAME
MC BOX
V
n: 230 V
F
n: 50/60
I
n stand-by: 40 mA
Pulser Max. Freq.: 60 Hz
Pulser Duty Cycle: 20%-80%
I
Motor Max: 6.5 A
IP 55
YEAR 2008
Read instruction
M0187 - M0188
CODE F1398000B
LOT NUMBER
0000001
CERTIFIED COMPANY
UNI-EN ISO 9001
PIUSI S.P.A.
SUZZARA
(MN) ITALY
EN
