FAZUA SOFTWARE
Update System Software
NOTE: A detailed video outlining the procedure for updating the system software can be found on the Fazua website:
https://fazua.com/en/magazine/update-motor-software-toolbox/
1. Open the Fazua Toolbox software and connect the drivepack. (Procedure provided above)
2. Go to https://fazua.com/en/drive-system/software/ and click on the "Drive System Software" link.
3. On the next page, under the "Latest Version" header, click the "Download" link. Note where this le is saved.
4. In the Fazua Toolbox software, at the bottom of the left panel, click on the "Software Update" menu.
5. In the "Software Update" menu, click on "Select Software" in the upper right hand corner. This will open a
document search menu.
6. In this menu, search for and open the recently downloaded "Drive System Software" le.
7. Click "Update"
8. Do not move the drivepack during the update process. Gently hold the drivepack in place, as possible
vibrations during calibration can move the drivepack.
9. Wait for the update to install and the motor calibration to complete.
10. Disconnect the USB cable and install the USB cap using a Torx T10 screwdriver. (Maximum Torque: 1.5 Nm)
11. Once you install the drivepack with the new motor software into the ebike, the remote will recieve an
update. The LEDs will ash during this process.
Saving Custom Assistance Proles
Once a custom conguration is created, click on "New", give the prole a name and click on "Save". All the
proles you have saved can be called up in the drop-down menu, even if the drivepack is not connected
to the computer. The various proles are saved to the Fazua Toolbox software and will be available in the
drop-down menu everytime the program is opened.
Setting Custom Assistance Proles
To transfer the custom settings to the drivepack, click the "Set Values" button at the top of the screen.
Importing Custom Assistance Proles
To import a prole, click on "Import". In the menu that appears, navigate to the location that the le is saved.
Select the le and click on "Open". The next menu will have all proles saved in that le appear with check
marks next to each. Select which proles to import and click on "Import". All selected proles to import will
now appear in the drop-down menu in the Fazua Toolbox.
Exporting Custom Assistance Proles
NOTE: Saved proles are saved to the Fazua Toolbox and are always available when the desktop software is opened.
The main reason to export a prole, would be to to send a custom prole to another user. This allows proles to
be shared and uploaded to another user's device.
Once a custom conguration has been saved to the Fazua Toolbox, it is available to be exported. To export
a prole, click on "Export". In the menu that appears, select which proles to export and click "Export".
All proles selected will be saved collectively as a set within a single .XML le. In the next menu, give the
prole set a name and click "Save". The saved le contains all proles that were selected and enables them
to be imported individually or as a group.
