Small Parts Table
SCHEMATICS
NUMBER PART NAME DESCRIPTION TORQUE *
4 FP-CVR-EVAULT-SKD-***-V1-R1 E-Vault Skid Plate
5 FP-MNT-BAT-EVAULT-V1-R1 E-Vault Di2 Battery Holder
6 FP-SCW-FLT-M8*25-V1-R1 M8x25 Flat Head Bolts for Skid Plate
7 FP-RDH-NUT-12MM-BLK-V1-R1 12mm RDH Nut V3 (Sleeve Compatible)
8 FP-RDH-TA-12MM-BLK-V4 Vault Derailleur Hanger
9 FP-SCW-SCK-M5*16 M5x16 Rear Derailleur Screw 7 Nm (5 lb·ft) G
10 FP-CLM-DUAL-FRM-V1 Internal Routing Dual Clamp
11 FP-CLM-MECH-FRM-V1 Internal Routing Cable Clamp
12 FP-CVR-MECH-FRM-V2 Internal Routing Hole Cover
13 FP-SCW-FLT-M3*10 M3x10 Cable Clamp Screw (Included w/ Clamp)
14 FP-FDM-BRZON-VLT-V1-R1 Front Derailleur Mount (Braze-On)
15 FP-SCW-FLT-M4*10-V1-R1 M4x10mm FDM/Di2 Battery Bolts
16 FP-PLG-FD-56.8*20.8*3-V1-R1 Front Derailleur Plug
17 FP-GDE-DI2-7*8*5*2.5 7x8mm Di2 Wire Guide Ext'd for Di2 FD
18 FP-PLG-DI2-7*8*5 7x8mm Di2 Plug Ext'd
19 FP-MNT-FDR-UPPER-V1-R1 Upper Fender Mount
20 FP-MNT-FDR-LOWER-V1-R1 Lower Fender Mount
21 FP-SCW-BTN-M4*8-V1-R1 M4x8 Fender Mounting Bolts
22 FP-SCW-BTN-M5*8 M5x8 Button Head Screw
23 FP-SCW-BTN-M5*10 M5x10 Button Head Screw
24 FP-GRM-20MM-BLK-V1-R1 Di2 Battery Anti-rattle Grommet
25 FP-CLM-DI2-SLV-BLK-V1 Di2 Wire Sleeve for Cable Clamps
26 FP-SCW-BTN-M5*12 M5x12 Button Head Screw
27 FP-WSH-O-RING-EVAULT-V1-R1 O-Ring for Internal Cable Management
28 FP-CLM-VELCRO-28*12-V1-R1 Velcro for Cable Management
29 FP-PRO-FOAM-100*30-V1-R1 Internal Foam (100x30)
30 FP-PRO-FOAM-75*30-V1-R1 Internal Foam (75x30)
31 FP-PRO-FOAM-55*20-V1-R1 Internal Foam (55x20)
32 FP-SLV-STPOST-27.2-V1-R1 27.2mm Seat Post Insert for Rigid Post
32 FP-SLV-STPOST-30.9-V1-R1 30.9mm Seat Post Insert for Dropper Post
33 FP-CLM-STPOST-LKRING-V1-R1 Seat Post Lockring
34 FP-CLM-FLXPOST-27.2-V1-R1 27.2mm Seat Post Clamp
34 FP-CLM-FLXPOST-30.9-V1-R1 30.9mm Seat Post Clamp
35 FP-SCW-SCK-M5*15 Seat Post Clamp Screw
36 FP-RDH-SLV-VAULT-V1-R1 Rear Derailleur Hangr Sleeve
37 FRAME SIZE STICKER - XS/SM/MD/LG/XL Frame Size Sticker
101 - 100mm Front Axle 15 Nm (11 lb·ft) G
102 157MM THROUGH AXLE V4 157mm Rear Axle 15 Nm (11 lb·ft) G
* PRODUCT TYPE RECOMMENDED PRODUCT
G Grease Motorex Bike Grease 2000
A Anti-Seize Motorex Copper Paste
L Thread Locker Loctite 243
