Wiring Diagram
SCHEMATICS
------------------------------------------------
Controller Wire
------------------------------------------------
Speed Sensor Wire
------------------------------------------------
Shimano 4 way Junction Box
------------------------------------------------
Di2 Battery Wire (300mm)
------------------------------------------------
Di2 Front Derailleur Wire (300mm)
------------------------------------------------
Di2 Rear Derailleur Wire (550mm)
------------------------------------------------
Di2 Shifter Wire (1000mm)
To Next Page
