21 EN
27 Alarm 1 Setpoint Protection: Alarm 1 set protection.
Does not allow user to modify setpoint
Modifi cation allowed (Default)
Protected
Protected and not visualized
28 Conversion Filter: ADC Filter: Number of input
sensor readings to calculate mean that defi nes process value.
N.B.: When readings increase, control loop speed slows down
Disabled
2 Samples Mean (mean with two samplings)
3 Samples Mean
4 Samples Mean
5 Samples Mean
6 Samples Mean
7 Samples Mean
8 Samples Mean
9 Samples Mean
10 Samples Mean
11 Samples Mean
12 Samples Mean
13 Samples Mean
14 Samples Mean
15 Samples Mean
29 Conversion Frequency: Sampling frequency of digital /
analogue converter.
N.B.: Increasing the conversion speed will slow down
reading stability (example: for fast transients, as the
pressure, it is advisable to increase sampling frequency)
242 Hz (Maximum speed conversion)
123 Hz
62 Hz
50 Hz
39 Hz
33.2 Hz
19.6 Hz
16.7 Hz (Default) Ideal for fi ltering noises 50 / 60 Hz
