11 Table of configuration parameters
GROUP A -
A.i n.1
- Analogue input 1
1  SEN.1 Sensor AI1
Analogue input configuration / sensor AI selection
tc. k Tc-K -260° C..1360° C. (Default)
tc. s Tc-S -40° C..1760° C
tc. r Tc-R -40° C..1760° C
tc. J Tc-J -200° C..1200° C
Tc. T Tc-T -260° C..400° C
tc. E Tc-E -260° C..980° C
tc. N Tc-N -260° C..1280° C
tc. b Tc-B 100° C..1820° C
Pt10 0 Pt100 -200° C..600° C
ni1 0 0 Ni100 -60° C..180° C
ntc 1 NTC 10K β3435K -40° C..125° C
Ptc PTC 1K -50° C..150° C
Pt500 Pt500 -200° C..600° C
Pt1k Pt1000 -200° C..600° C
0-1 0..1 V
0-5 0..5 V
0-10 0..10 V
0-20 0..20 mA
4-20 4..20 mA
0-60 0..60 mV
Po t. Potentiometer (set the value on parameter 6)
ni12 0 Ni120 -60 °C..240 °C
ntc 2 NTC 10K β3694K -40 °C..150 °C
ntc 3 NTC 2252 β3976K -40 °C..150 °C
2
 d .P.1 Decimal Point 1
Select number of displayed decimal points for AI
0 Default
0.0 1 decimal
0.0 0 2 decimals
0.000 3 decimals
3
 d eGr. Degree
°C Celsius (Default)
°F Fahrenheit
K Kelvin
4
 L.L.i .1 Lower Linear Input AI1
AI lower limit only for linear signals. Ex.: with input .. mA this parameter takes value associated
to  mA. The value may be greater than the one entered on the next parameter.
-..+ [digit
 p. 
] Default: .
5
 u .L.i .1 Upper Linear Input AI1
AI upper limit only for linear signals Ex: with input .. mA this parameter takes value associated
to  mA.The value may be lower than the one entered on the previous parameter.
-..+ [digit
 p. 
] Default:
6
 P. vA.1 Potentiometer Value AI1
Selects the value of the potentiometer connected on AI
.. kohm. Default: kohm
