2
Introduction
Thanks for choosing a Pixsys controller.
As all Pixsys instruments model ATR241 is highly configurable.
Input is selectable for a wide range of sensors (including load
cells with signal 0…40mV). Output is available as relay for
command and/or alarm but also as SSR or linear in different
options. To simplify the start-up and the configuration of the
device, a special Memory card allows to copy all parameters
and/or to store them for archive purpose without PC.
Additional software functions include Auto-tuning for optimal
rating of PID-parameters, Soft-start, retransmission of process or
setpoint with signal 4…20mA and the possibility to program a
short cycle for drying or firing profiles on small kilns.
Sealing of frontal panel according to IP54. Frontal extraction of
electronics.
1. Ordering codes
ATR241-
o
Power supply A
24V AC ±15% 50/60Hz
AD
24…12V AC/DC ±15% 50/60Hz
BC
230/115V AC ±15% 50/60Hz
