25
11. Technical data
11.1 Main features
Visualizers 8 displays, 0,40 inches
Operating conditions Operating temperature 0-45°C,
humidity 35..95uR%
Sealing IP54 Frontal panel
Material ABS self-extinguishing
Weight 270g
Dimensions 48x48(frontal)x112mm
11.2 Hardware data
Analog input AN1
Sampling frequency : 15Hz with filter set to 1,
0,5 Hz with filter set to 15
Configurable via software
For TC type K, S, R, J
Automatic compensation
cold junction 0 to 50°c
RTD type PT100,
Ni100
Input 0-10V,
0-20mA,
4-20mA,
0-40mV
Accuracy (25°C)
±0.2 % ± 1 digit
for TC, RTD, V,
mA,mV
Cold junction
accuracy:
0,1 °C/°C
Relay outputs OUT1, OUT2.
Configurable for command
or alarm
Contacts
capacity
8A-250V~
Output 0/4..20mA or SSR alternative to relay OUT2
Configurable as control
output or retransmission of
setpoint or process.
Configurable as
4...20mA,0-
20mA
Resolution:
2000 points
