D. Repeat the second piece of
wire in the same way. You get a
frame with two pieces of wire
soldered across.
Note! If you intend to use other contact wires (than Pt) or a
diameter other than the recommended (50 μm), or another
frame contact (different length of wires) or even other types
of wires. T
he appropriate changes must be made to the
measurement program settings.
Go to section 3.1.3 "Software"
3.2.4. Pellet sample mounting
Prepare materials and equipment (Table 4).
Follow the instructions:
Take the test sample of a
thermoelement of suitable size
(Table 3).
Note! Working
thermoelements are used to manufacture
thermoelectric modules. This means that the thermoelements
must have already special coating on two sides - barrier layer
(usually nickel) and a layer of tin (or gold) for soldering on the
ends.
