Z-Meter DX4091/ User Guide PL Engineering Ltd
ver. 1.02 (2022) page 27 of 44
Pour acetone over sample and
soldering areas to remove flux
residues.
Clear pellet by brush slightly.
Note! The accuracy of measurements subsequently
depends on the accuracy and completeness of flux removal.
The sample measuring frame
prepared in this way is shown in
the figure.
3.2.5. Pellet sample dismounting
The test frames included are for reusable use.
When used carefully, the test frame with mounted Pt wires can be
reused. To do this, after a measurement, the sample must be
