1. (power),
2.
3. BAND(band) button
5. (pause/play), Preset station1 button
6. INT (intro) 2 button
7. RPT (repeat) 3 button
8. RDM (random) 4 button
9. -10(previous 10 tracks) 5 button
10. +10(next 10 tracks) 6 button
11. CLK (clock setting) button, (end call) button
12. (tune down, seek down,track down, fast reverse) button
13. (tune up, seek up, track up, fast forward)button
14. MUTE button
16. EQ (Equalizer)
15. LOUD (Loudness) button
17.
SRC (source) button
, (answer call) button
4. AMS (automatic store / preset station scan, automatic music search) button
, Preset station
, Preset station
, Preset station
, FLR-(previous folder), Preset station
, FLR+(next folder), Preset station
(eject) button
18.Discslot
19. IR remote sensor
20. LCD Display
21. USB Port
22. AUX IN (aux audio input) jack
23. Hands-free Microphone
24. Reset button
CONTROL PANEL BUTTON LOCATIONS
4
Volume knob, (Push-To-Talk) button, select/menu button
