PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD
TRIGGER ASSEMBLY
6-32UNC X 0.1875 SOCKET SET
SCREW - CUP POINT
M2.5 X 5 CAP HEAD
SOCKET SCREW
TRIGGER SHOE
TRIGGER
6-32UNC X 0.1875 SOCKET
SET SCREW - CUP POINT
6-32UNC X 0.1875 SOCKET
SET SCREW - CUP POINT
