SERVICE INDICATOR - *SERVICE REQUIRED PART 1/2
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
(C) = CLEAN & INSPECT (R) = LUBRICATE
L
I
021 NBR70 O-RING
016 NBR70 O-RING
012 NBR70 O-RING
SPOOL (OUTSIDE FACE)
011 NBR70 O-RING
SWTCH BODY (INSIDE FACE)
SWITCH (INSIDE FACE)
L
L
L
L
I
I
I
I
I
I
I
*In addition to the ‘lubrication’ guide on previous page
