PLANET ECLIPSE 180R.68CAL - Inefficient; Low Shot Count

28
PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD
(C) = COMMON FAULT (R) = RARE FAULT
INEFFICIENT / LOW SHOT COUNT
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
6 X 1.5 NBR70 O-RING (R)
016 NBR70 O-RING (C)
021 NBR70 O-RING (C)
012 NBR70 O-RING (R)
R
R
R
C
SWITCH
SPOOL
BOLT GUIDE
SWITCH BODY
C
C
