PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD
180R BOLT SYSTEM
NOTE: CS3 AND 180R SPOOL ASSEMBLIES AND JOINER PARTS ARE NOT INTERCHANGABLE
CAN
SPOOL SPRING
SWITCH
PLUNGER
010 NBR70 O-RING
M2.5 SPRING WASHER
SWITCH BODY CAP
BOLT PIN
4X1 NBR 70 O-RING
SPRING GUIDE
SWITCH BODY
5MM BALL BEARING
SPOOL
JOINER
BOLT
BOLT GUIDE
BOLT BONNET
M2.5 X 8 CAP HEAD SOCKET SCREW
