PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD
(C) = CLEAN & INSPECT (R) = LUBRICATE
SERVICE INDICATOR - LUBRICATION REQUIRED
CLEAN, INSPECT & LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
L
I
CAN (INSIDE FACE)
020 NBR70 O-RING
017 NBR70 O-RING
14X2 NBR70 O-RING
BOLT (OUTSIDE FACE)
6X1.5 NBR70 O-RING
017 NBR70 O-RING
BOLT (INSIDE FACE)
L
L
L
L
L
L
L
L
L
I
I
I
I
I
I
I
I
I
015 NBR90 O-RING
013 NBR70 O-RING
013 NBR70 O-RING
013 NBR70 O-RING
I
I
I
