19
Figure 2-5-2: Insert a Gigabit Media Converter into an available slot
1. Never push the converter into the slot with
violent, it could damage the chassis.
2. The Media Converter Chassis supports hot-
swap; there is no need to turn off the whole
chassis before slide in the new converter.
2.5.3 Optional DIN-Rail Installation
There are two DIN-Rail holes on the left side of the GT-1205A
that allows it can be easily installed with DIN-Rail mounting. The
PLANET optional DIN-Rail mounting Kit – RKE-DIN can be order
separately. When need to replace the wall mount application
with DIN-Rail application on the GT-1205A, please refer to
following gures to screw the DIN-Rail on the GT-1205A. To
hang the GT-1205A, follow the below steps:
Step 1: screw the DIN-Rail on the GT-1205A
