2. Hardware Description
This product provides three different running speeds – 10Mbps,
100Mbps and 1000Mbps in the same Gigabit Media Converter
and automatically distinguishes the speed of incoming
connection.
This section describes the functionalities of GT-1205A’s
components and guides how to install it on the desktop or shelf.
Basic knowledge of networking is assumed. Please read this
chapter completely before continuing.
2.1 Product Outlook
The GT-1205A overview showed as below:
3-Port Media Converter
10/100/1000 Base-T to Dual 10 00Base-X SFP
1000
1
1
2
2
3
PWR
LNK/
ACT
10/100/1000Base-T to Dual 1000Base-X SFP
5V DC
Rear Panel Front Panel
TOP Panel Bottom
Figure 2-1-1: GT-1205A Overview
