A.3 Fiber-Optic Cable Connection Parameter
The wiring details are as below:
Cables:
Standard Fiber Type Cable Specication
1000Base-SX (850nm) Multi-mode
50/125μm or
62.5/125μm
1000Base-LX (1300nm)
Multi-mode
50/125μm or
62.5/125μm
Single-mode 9/125μm
Wiring Distances:
Standard Fiber
Diameter
(micron)
Modal
Bandwidth
(MHz * km)
Max.
Distance
(meters)
1000Base-SX MM 62.5
62.5
50
50
100
200
400
500
220
275
500
550
1000Base-LX
MM 62.5
50
50
5
4
5
550
SM 9 N/A 5000*
