; 802.1p Tag Priority / IP address priority / IP DSCP option in Quality of Service Mode and Strict Priority /
Weighted Round Robin (WRR) QoS policies
; TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test
; 16 TCP / UDP Filter groups
; Password setting, IP setting and devices description setting through Planet Smart discovery utility
; Firmware upgrade via remote Web interface
External DC 5V 2A power supply
Compact in size, easy installation
LED indicators for easy network diagnosing
Reset Button at the front panel for resetting the factory default
Choice of fiber-connector from SC, LC, WDM, multi-mode / single-mode fiber /1000Base-SX / LX mini GBIC
module
1.5 PRODUCT SPECIFICATION
Model GT-902 GT-902S GT-905A GT-906A15 GT-906B15
Hardware Specification
Standards
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX
IEEE 802.3ab, 1000Base-T
IEEE 802.3z, 1000Base-SX/LX
Ports
1 x 10/100/1000Base-T port,
1 x 1000Base-SX/LX / LX WDM port
1 x 1000Base-SX/LX SFP slot
Copper Interface RJ-45 port (Auto-MDI/MDI-X) Twisted Pair
Optic Interface SC SFP WDM
Optic Wavelength 850nm 1310nm -
TX:1310nm
RX:1550nm
TX:1550nm
RX:1310nm
Max.
-4 dBm -3 dBm -
-3 dBm
+5 dBm
Launch
Power(dBm)
Min.
-9.5 dBm -9.5dBm -
-9 dBm
0 dBm
Receive Sensitivity -13.5 dBm -14.4 dBm - -21 dBm -25 dBm
Maximum Input power -18 dBm -20 dBm - -3 dBm -3 dBm
Twisted-pair
10/20Mbps for Half / Full-Duplex
100/200Mbps for Half / Full-Duplex
2000Mbps for Full-Duplex
Speed
Fiber-optic 2000Mbps for Full-Duplex
Twisted-pair
10Base-T: 2-pair UTP Cat. 3,4,5, up to 100 m
100Base-TX: 2-pair UTP Cat. 5, up to 100 m
1000Base-T: 4-pair STP Cat 5 up to 100m
Cable
Fiber-optic
Cable
50/125μm or 62.5/125μm multi-mode fiber cable, up to 220/550m.
9/125μm single-mode cable, provides long distance for
10/15/20/30/40/50/70/120km (very on fiber transceiver or SFP module)
LED Indicator y PWR,
y TP LINK/ACT, 1000
y Fiber LINK/ACT
Power Consumption 3.8 Watts/ 13 BTU (maximum)
Power Input DC 5V / 2A
