HDMI / Video Wall over IP with PoE
IHD-200PT / IHD-200PR
16
Chapter 2: Hardware Installation
z The Unit-Cast application is Plug-and-Play basis. It’s easy to install in seconds.
z The Multi-Cast application can be used as multi-to-multi and video wall which is
suitable for digital signage.
2.1 Installation Instructions
System Requirements
1. HDCP compliant monitors with HDMI interface for the HDCP video source
2. CAT5 / 5e / 6 UTP cable (EIA / TIA 568B industry standard compliant)
3. PoE Switch (see Recommended PoE Switch)
Application Recommended Ethernet Switch
Video Wall Application Gigabit PoE Switch, IGMP & Snooping function
Multiple Video Wall Application
Gigabit PoE Switch, IGMP, Snooping function & VLAN
function
Operation:
The LED on the Extender Units shows the real-time status indicating the linking and
communication between the Transmitter/Sender Unit and the Receiver Unit. Users
can identify the current status through the LED indicators on the unit.
The quality of the output signal will depend largely upon the quality of video source,
cable and display device used. Low quality cables degrade output signal causing
elevated noise levels. Please use the proper cable and make sure the display device
is capable of handling the resolution and refresh rate selected.
Step 1
Connect the video source to the Transmitter / Sender Unit.
Step 2
Connect the monitor to the Receiver Unit.
Step 3
Use CAT5 cables (EIA / TIA 568B industry standard compliant) for connection
between TX / RX and Gigabit PoE Switch.
Step 4
Set an identical ID number on Rotary DIP Switch for all Units of the same group.
Step 5
User still could apply the proper power to all connecting devices if without PoE
switch.
