Planet ISW-504PT User Manual

10
Network cables
1. 10/100Base-TX:
Cat. 3, 4, 5,
5e, 6 UTP cable
(100meters max.)
2. EIA/TIA-568
100-ohm STP
(100meters max.)
3. Single-mode optic
ber 9 / 125μm
(15km max.)
1. 10/100Base-TX:
Cat. 3, 4, 5,
5e, 6 UTP cable
(100meters max.)
2. EIA/TIA-568
100-ohm STP
(100meters max.)
3. 50 / 125µm or
62.5 / 125µm
multi-mode ber
cable, up to 220 /
550m
4. 9 / 125µm single-
mode cable,
provides long
distance for 10 /
15 / 20 / 30 / 40
/ 50 / 60 / 70 /
120km
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
Temperature
Operating: -40 to 75 Degree
Storage: -40 to 85 Degree
Humidity
Operating: 5~90%
Storage: 5~90% (Non-condensing)
Regulation Compliance FCC Part 15 Class A, CE
Stability testing
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)

Planet ISW-504PT Specifications

General

Brand	Planet
Model	ISW-504PT
Category	Switch
Language	English
