Model ISW-514PT15 ISW-514PTF
Hardware Specication
10/100Base-TX Ports 4 4
100Base-FX interface 1 1
IEEE 802.3af PoE ports 4 4
Dimensions (W x D x H) 135mm x 87.8mm x 56mm
Weight 842g
Power Requirement 24 or 48V DC
Installation DIN Rail Kit and Wall Mount Ear
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply Type End-Span
PoE Power Output 48V DC Per Port, 350mA. Max. 15.4 Watts
Power Pin Assignment 1/2(+), 3/6(-)
Switch Specication
Switch Processing Scheme Store-and-Forward
Address Table 2K entries
Flow Control
Back Pressure for Half Duplex
IEEE 802.3x Pause Frame for Full Duplex
Switch fabric 1Gbps
Throughput
(packet per second)
0.74Mpps
