Planet KVM-210-08M User Manual

7
3.2 Rear Panel of IP Module (IKVM-210-08M/IKVM-210-16M only)
Reset Reboot
LAN
Interface Description
LAN Port One 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port.
Reboot Press and release to restart the system.
Reset Press for 5 seconds to reset to factory default.
3.2.1 System Requirements
PLANET IKVM Series provides an IPKVM utility to remotely control the server.
The following are required for further management:
CPU Intel Dual Core 2.0GHz or higher
RAM 2GB or above recommended
Video RAM 128MB or above recommended
Operating System Windows 7/10 or higher
Video Resolution
800x600, 1024x768, 1280x720, 1280x800, 1280x1024,
1920x1080
Browser version
 IE10.0 or higher
 Firefox 48.0.2 or higher
 Google Chrome 23.0.1271.97m or higher
