11
Functionality DIP Switch Select Master or Slave mode
Dimensions
(W x D x H)
97 x 70.3 x 26 mm
Weight 194g
Housing Metal
Power Requirement 5V DC, 2A external power
LED Indicators
Power: Green
LAN: Green, 10/100Mbps LNK/ACT
Long Reach: Green, LNK
Master: Green
Standards Conformance
Standards Compliance
IEEE 802.3/802.3u Ethernet standard compliant
IEEE 802.3x Full-duplex ow control
IEEE 802.1q Tag VLAN Transparent, Multicast pass-
through
Regulatory Compliance FCC Part 15 Class A, CE
Environment
Temperature
Operating: 0~50 degrees C
Storage: -10~70 degrees C
Humidity
Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
**The RJ45 port only supports 10/100TX Ethernet.
*** The actual data rate will vary in the quality of the UTP cables or Phone
wire and environmental factors.
