2. Hardware Introduction
2.1 Physical Dimensions
Dimensions (W x D x H): 94 x 70.3 x 26.2mm
26.20
94.00
70.30
46.70
∅7.00
Unit: mm
5V DC
Master Slave
Long Reach Ethernet
10/100TX over UTP Extender
Long Reach Ethernet over UTP Extender
LRE-101
LNK/
ACT
PWR
LNK
Master
LAN
10/100TX
Long Reach
