Planet LRP-101C-KIT User Manual

11
Long
Reach
PoE
Interface
Power Input ─ 37~56V DC
Power Output 41~56V DC ─
Power Pin
Assignment
 BNC center pole :
DC+
 BNC shield : DC -
 BNC center pole :
DC+
 BNC shield : DC -
Cabling
Coaxial cable: 75 ohm
RG-6/U cable, less than 12Ω/1000 ft
RG-59/U cable, less than 30Ω/1000 ft.
Maximum
Distance
Max. 200m with PoE+ output (656ft.)
Max. 600m with PoE output (1968ft.)
Max. 1200m without PoE output (3,937ft.)
Long Reach
Ethernet
Standard
IEEE 1901
Modulation Type Wavelet-OFDM
Security 128-bit AES encryption
Frequency Band 2 ~ 28 MHz
Encryption AES 128-bit
Performance**
Distance
Data Rate*
(Upload /
Download)
LRP-101CE 802.3af/at
PoE Output Capability**
LRP-101CH
W/56V DC
IN
LRP-101CH
W/30W
PoE+ IN
200m 93 / 93 Mbps 29W 16W
400m 93 / 93 Mbps 22W 14W
600m 87 / 91 Mbps 13W 10W
800m 75 / 83 Mbps 10W 8W
1000m 55 / 73 Mbps 8W 7W
